ERGONOMICAL DIE REWORK
For ergonomic rework of upper dies in the tryout phase, it is preferable to turn them to an ergonomically favorable position. Die turnover devices are used for safe opening and turning, and can be connected to the tryout presses using moving bolsters. Die turnover devices simplify die handling, so that the dies are subsequently available to the production presses more quickly.
| MODEL | Slide Force(Kn) | Bolster size (mm) | Motor (Hp) | Daylight (mm) | Stroke (mm) |
| MAD-50 | 500 | 2000 x 1500 | 25 | 1500 | 1500 |
| MAD-100 | 1000 | 2000 x 1500 | 50 | 1500 | 1500 |
| MAD-200 | 2000 | 3000 x 2000 | 75 | 2000 | 2000 |
| MAD-300 | 3000 | 3000 x 2000 | 100 | 2000 | 2000 |
ADVANTAGES
- Simple opening and turning of the dies.
- Ergonomic rework of the turned dies.
- Integration into tryout centers using rail systems and moving bolster.
