| Capacity | Wire Diameter | 0.6-2.5 mm |
|---|---|---|
| Max. Width of Strip | 30 mm | |
| Thickness of Strip | 0.3-1.2 mm | |
| Hardness of Strip | 80 (CARBON) | |
| Length of Feeding | 200 mm | |
| Max. Forming Speed | 200 ppm | |
| Tonnage | Press Capacity | 10 Tons |
| Slide Capacity | 1.5 Tons | |
| Stroke | Press Stroke | 12 mm |
| Slide Stroke | 37 mm | |
| Machine | Motor Rating | 5.0 HP (3.7 KW) |
| Machine Size (LxBxH) | 2000 x 990 x 1900 mm | |
| Weight | 2100 kgs |
