| Capacity | Wire Diameter | 0.1-1.0 mm |
|---|---|---|
| Max. Width of Strip | 10 mm | |
| Thickness of Strip | 0.04-0.5 mm | |
| Hardness of Strip | 80 (carbon) | |
| Length of Feeding | Unlimited | |
| Max. Forming Speed | 250 ppm | |
| Tonnage | Press Capacity | 1.5 Tons |
| Slide Capacity | 0.4 Tons | |
| Stroke | Press Stroke | 8 mm |
| Slide Stroke | 20 mm | |
| Motor Rating | Feeding | 1.0 HP (0.75 KW) |
| Press and Forming | 2.0 HP (1.5 KW) | |
| Machine | Machine Size (LxBxH) | 1500 x 900 x 1800 mm |
| Weight | 750 kgs |
