Automatic Forming Machines 自動成型機 / YSM CNC-39T
| Capacity |
Wire Diameter |
1.5-6.5 mm |
| Max. Width of Strip |
60 mm |
| Thickness of Strip |
0.8-3.0 mm |
| Hardness of Strip |
80 (CARBON) |
| Length of Feeding |
Unlimited |
| Max. Forming Speed |
150 ppm |
| Tonnage |
Press Capacity |
40 Tons |
| Slide Capacity |
8 Tons |
| Stroke |
Press Stroke |
40 mm |
| Slide Stroke |
60mm |
| Motor Rating |
Feeding |
2 HP (1.5 KW) |
| Press |
15 HP (12 KW) |
| Forming Cam |
15 HP (12 KW) |
| Ejection Axis (Optional) |
1.3 HP (1 KW) |
| Rotation Axis (Optional) |
0.5 HP (0.4 KW) |
| Machine |
Machine Size (LxBxH) |
3500 x 1800 x 2350 mm |
| Weight |
6800 kgs |
| Optional Part |
Safety Guard |
Automatic Forming Machines / YSM CNC-39T
