Automatic Forming Machines 自動成型機 / YSM CNC-26TP
| Capacity |
Wire Diameter |
0.6-2.5 mm |
| Max. Width of Strip |
30 mm |
| Thickness of Strip |
0.3-1.2 mm |
| Hardness of Strip |
80 (CARBON) |
| Length of Feeding |
Unlimited |
| Max. Forming Speed |
200 ppm |
| Tonnage |
Press Capacity |
10 Tons |
| Slide Capacity |
1.5 Tons |
| Stroke |
Press Stroke |
12 mm |
| Slide Stroke |
37 mm |
| Motor Rating |
Feeding |
2.0 HP (1.5 KW) |
| Press and Forming |
4.5 HP (3.5 KW) |
| Rotation Axis (Optional) |
0.5 HP (0.4 KW) |
| Machine |
Machine Size (LxBxH) |
2550 x 990 x 1800 mm |
| Weight |
2900 kgs |
Automatic Forming Machines / YSM CNC-26TP
