| Capacity | Wire Diameter | 0.6-3.2 mm |
|---|---|---|
| Max. Width of Strip | 40 mm | |
| Thickness of Strip | 0.3-1.5 mm | |
| Hardness of Strip | 80 (CARBON) | |
| Length of Feeding | Unlimited | |
| Max. Forming Speed | 200 ppm | |
| Tonnage | Press Capacity | 15 Tons |
| Slide Capacity | 3.0 Tons | |
| Stroke | Press Stroke | 16 mm |
| Slide Stroke | 60 mm | |
| Motor Rating | Feeding | 2.0 HP (1.5 KW) |
| Press | 4.5 HP (3.5 KW) | |
| Forming Cam | 3.0 HP (2.2 KW) | |
| Rear Processing | 1.5 HP (1.1 KW) | |
| Rotation Axis (Optional) | 0.5 HP (0.4 KW) | |
| Machine | Motor Rating | 2.0 HP (1.5 KW) |
| Machine Size (LxBxH) | 2250 x 990 x 1800 mm | |
| Weight | 2500 kgs |
