| Capacity | Wire Diameter | 0.1-1.0 mm |
|---|---|---|
| Max. Width of Strip | 10 mm | |
| Thickness of Strip | 0.04-0.5 mm | |
| Hardness of Strip | 80 (CARBON) | |
| Length of Feeding | Unlimited | |
| Max. Forming Speed | Based on Products | |
| Forming | Slide Capacity | 0.4 Tons |
| Slide Stroke | 20 mm | |
| Motor Rating | Feeding | 1.0 HP (0.75 KW) |
| Forming | 1.2 HP (1.0 KW) | |
| Machine | Machine Size (LxBxH) | 2000 x 1200 x 1800 mm |
| Weight | 750 kgs |
