| Capacity | Wire Diameter | 0.6-3.0 mm (Max. of 6.0mm avaliable) |
|---|---|---|
| Hardness of Wire | 80 (CARBON) | |
| Length of Feeding | 200 mm | |
| Max. Forming Speed | 200 ppm | |
| Forming | Slide Capacity | 1.5 Tons |
| Slide Stroke | 33 mm | |
| Machine | Motor Rating | 3.0 HP (2.3 KW) |
| Machine Size (LxBxH) | 1800 x 800 x 1850 mm | |
| Weight | 1200 kgs |
